Repair Panels

Technical Specifications Installation Instructions

Cut from Gyprock Plus 10mm plasterboard panels, Repair Panels are strong and light making them easy to handle and extremely durable. Gyprock Repair Panels are conveniently sized pieces of plasterboard used for repairing holes and other damage in plasterboard walls and ceilings.

Product Overview

Gyprock Repair Panels are available in two sizes:

  • Repair Panel – available as a 1200mm long by 900mm wide panel with the shorter edges recessed for flush jointing.
  • Mini Repair Panel – available as a 530mm wide by 530mm long panel and ideal for smaller wall and ceiling repairs. These panels are suitable for use in 600mm x 600mm access frame kits.

Typical Applications

Gyprock Repair Panels can be used to repair holes and damage such as holes, dents and scrapes in residential walls and ceilings where there are no specific fire, acoustic or moisture resistance requirements.

Use with DIY Compounds

Doing the repair yourself? Use Gyprock DIY compounds with your Gyprock Repair Panels.

The Gyprock DIY range of compounds is available for the easy installation and repairs of Gyprock plasterboard and cornice. These products are designed with the needs of a home handyman and DIY enthusiast in mind with smaller, convenient pack sizes and product formulations that streamline the installation process – all with easy to follow instructions on the packs.

Gyprock® Repair Panel
Product Data Sheet Safety Data Sheet Find a Supplier
Australian Made logo in black and white

Australian Made

Licensed by Australian Made Campaign Ltd
size options with two different sized objects

Two Handy Sizes

Catering for both smaller and larger repair jobs

lighter icon with feather

Lighter

Easy to lift and flex for better sheet manoeuvrability

improved score icon with cutting blade

Improved Score and Snap

For crisp edges and cleaner cuts

Technical Specifications

Product Options

Gyprock Repair Panels are available in the following sizes:

Repair Panel

Thickness 10mm
Width 900mm
Length 1200mm

Mini Repair Panel

Thickness 10mm
Width 530mm
Length 530mm

Stockholdings may vary. For product availability and to place an order, contact your nearest supplier.

Product Manufacture

Gyprock Repair Panels are manufactured by CSR Gyprock in Australia to stringent product specifications.

Product Handling

Transportation and manual handling: Refer to the Gypsum Board Manufacturers of Australia (GBMA) website for recommended OH&S practices.

Storage: Protect plasterboard and cornice from weather and moisture. Avoid products sagging by storing horizontally, supported on a level platform or full-width support members spaced at max. 600mm centres.

Health and Safety

Safety Data Sheets are important documents in the construction industry and assist in the continuing focus on occupational health and safety on and off sites.

Manufacturing Tolerances

Nominal Thickness 10mm ± 0.5mm
Nominal Widths 1200mm ± 3mm
Nominal Lengths 900mm ± 5mm
Squareness Cut ends ± 3mm in the width of the board

Physical Properties

Nominal Board Weight* 5.7kg/m2
Thermal Performance:
R-Value		 0.07 m2K/W
Fire Hazard: assessed to AS/NZS3837 cone calorimeter test Average Specific Extinction Area (ASEA)
<250m2/kg
Group Number 1
Report Reference WFRA 45759
Combustibility In accordance with BCA Clause C1.12, Gyprock Repair Panel may be used wherever a non-combustible material is required by the Code.

*Subject to reasonable manufacturing variance.

Installation Instructions

Installing to Standards

AS/NZS2589: Gypsum linings – Application and Finishing outlines the procedures for the installation and finishing of Gyprock Repair Panels in conjunction with additional details contained in Gyprock Technical Literature.

Resources

Gyprock makes available resources that provide comprehensive selection, design, installation and maintenance guidance.

Man repairing a hole in the wall

DIY Video & Guide

Repairing Gyprock Plasterboard - watch the video or download the guide

Australian Made

Australian Made

Licensed by Australian Made Campaign Limited to use the Australian Made Logo.
Manufactured For Life red logo with the shape of Australia in the centre.

Manufactured for Life

Gyprock plasterboard products are manufactured for life with all CSR products designed to achieve optimal performance when part of a CSR integrated system.

GECA Accredited

Verified by an independent conformity assessment body to meet the environmental, health and social/ethical criteria of the GECA Panel Boards standard.
